Wiki for Onboard Frequency Analyzer (OFA)-Plasma Wave Investigation (PWI) onboard BepiColombo Mercury Magnetospheric Orbiter (BC/MMO)
The EWO consists of three sets of receivers: EWO-EFD (Electric Field Detector), EWO-WFC/OFA(E) (Wave-Form Capture/Onboard Frequency Analyzer for Electric field), and EWO-WFC/OFA(B) (WFC/OFA for Magnetic field) [Sec.5 of Kasaba et al. (2020a)]. Those receivers observe waveforms and spectra in the frequency range from DC (very low frequency) to 120 kHz for the electric field and from 0.3 Hz to 20 kHz for the magnetic field. The EWO covers the frequency range of various plasma waves in and around the Hermean magnetosphere. The basic design is similar to that of the PWE EWO unit aboard the Arase PWE (Kasahara et al. 2018a; Kasaba et al. 2017).
Members
Instrument team
- Yasumasa Kasaba (Tohoku University, Japan)
- Hirotsugu Kojima (Kyoto University, Japan)
- Satoshi Yagitani (Kanazawa University, Japan)
- Shoya Matsuda (Kanazawa University, Japan)
Data contact at Mio-SC
- Chae-Woo Jun (CHS, ISEE, Nagoya Univ., Japan)
- Tomoaki Hori (CHS, ISEE, Nagoya Univ., Japan)
Rules of the Road for the data users
Updates on the instrument status, data, and any notes
- N/A
Instrument Specifications
Data release/version history
- TBD: the first release of Lv.2pre data (data ver.: r01-v03-00) to registered users.
Calibration Information
Science Data Products
Level-2pre (cruise phase) data products
File name convention
- bc_mmo_pwi-ofa_l2p_Data mode-spec-Observation mode_YYYYMMDD_rXX-vYY-ZZ.cdf
- Data mode: low (L), medium (M), and high (H) modes.
- Observation mode: magnetosphere (MS) and solar wind (SW) modes.
- Version number:
- XX: release version
- YY: major version
- ZZ: minor version
Level-2pre OFA (B) Data (calibrated B field)
- For L-mode,
- AA:18, 36, 72 pts
- Nominal time resolutions: 2-8 sec
- For M-mode,
- AA: 90, 180, 360 pts
- Nominal time resolution: 1-8.3 sec
| Variable name | Description | Dimension | Remarks |
|---|---|---|---|
| epoch_bAA | Time labels in TIME_TT2000, at the center of each data accumulation period (bAA) | (time) | |
| epoch_eAA | Time labels in TIME_TT2000, at the center of each data accumulation period (eAA) | (time) | |
| strtime_epoch | epoch values in YYYY-MM-DDThh:mm:ss.fff format. | (time) | |
| epoch_delta1_bAA | Time diff. from the data accumulation start to epoch (bAA) | (time) | |
| epoch_delta1_eAA | time diff. from the data accumulation start to epoch (eAA) | (time) | |
| epoch_delta2_bAA | time diff. from epoch to the data accumulation end (bAA) | (time) | |
| epoch_delta2_eAA | time diff. from epoch to the data accumulation end (eAA) | (time) | |
| mdp_ti_bAA | TI values provided by MDP (bAA) | (time) | |
| mdp_ti_eAA | TI values provided by MDP (eAA) | (time) | |
| spec_Babs_AA | the magnetic field spectrum data with AA pts frequency channels | (time,freq_bAA) | |
| spec_Eabs_AA | the electric field spectrum data with AA pts frequency channels | (time,freq_eAA) | |
| freq_bAA | Frequency array (b_AA) | (freq_bAA) | |
| freq_eAA | Frequency array (e_AA) | (freq_eAA) | |
| bandwidth_bAA | Bandwidth array (b_AA) | (freq_bAA) | |
| bandwidth_eAA | Bandwidth array (e_AA) | (freq_eAA) | |
| quality_flag | quality flags for the data values | (time) |
Data Inventory (Data Archive Status)
- Data repository: TBD
| Dataset name | Processed from | Latest CDF version | Remarks |
|---|---|---|---|
| Level2 pre Spec CDF | TBD | r01-v03-00 |
